Stochastic Differential Equations: A Crash Course

This section is an adapted version of Appendix A of the corresponding publication [SCB+25].

A \(d\) dimensional stochastic process \(x(t)\) follows an Ito stochastic differential equation (SDE), if it satisfies

\[x_i(\overline{t})=x_i(\overline{t})+\int_{\underline{t}}^{\overline{t}} f_i(x(t'),t')dt'+\sum_{j}^{m}\int_{\underline{t}}^{\overline{t}} G_{ij}(x(t'),t')dW_j(t')\]

for all \(i\leq d,\ \underline{t}\leq \overline{t}\) and some vector valued drift function \(f:\mathbb{R}^d\times \mathbb{R}^+\to\mathbb{R}^d\) and diffusion function \(G:\mathbb{R}^d\times\mathbb{R}^+\to\mathbb{R}^{m\times d}\), where \(W:\mathbb{R}^+\to\mathbb{R}\) is a standard \(m\)-dimensional Wiener process. Such a process can be denoted in differential notation:

\[dx(t)=f(x(t),t)dt+G(x(t),t)dW(t)\]

Our model estimates both \(f\) and \(G\) in a zero-shot manner, where \(G\) is returned in the following form:

\[ G(x)=\text{diag}(\sqrt{g_1(x)},\dots,\sqrt{g_d(x)})\]

A few notes

1. The model and the tutorial assume, that both the drift and the diffusion are only state-dependent and not time dependent.

2. Some authors return a different scaling of \(G\):

\[\text{diag}(g_1(x),\dots,g_d(x)).\]

Therefore one should be careful when comparing results from different models/ authors!

The next section of this tutorial will demonstrate how one can use our model in practice to produce predictions for the underlying SDE of some given data.
